INFOADAPTER/RATBETJENING CITROEN/MITSUBISHI/PEUGEOT MED ROCKFORD FOSGATE

vehicles with SWC

connector: 18 Pin / 20 Pin Mitsubishi

to enter settings connect the reverse signal output (purple/white) to HU
for visualisation of the settings connect and configure the rear view camera input of the HU

vehicles with Rockford Fosgate OEM amplified system
vehicles with Mitubishi OEM HU
vehicles with MMCS OEM Sat Nav 18 Pin / 20 Pin Mitsubishi connector

vehicles without MMCS OEM Sat NAV with 17 Pin Honda connectorg grey

Rockford Fosgate OEM amplified settings supported (look manual)

blue: +12V Amp remote

Vehicle application:

Citroen
Citroen C-Crosser (V) 09/2007 - 10/2012

Mitsubishi
Mitsubishi ASX (GAO) 06/2010 - 09/2012
Mitsubishi ASX (GAO) 10/2012 - 09/2016
Mitsubishi ASX (GAO) 11/2016 - 08/2019
Mitsubishi ASX (GAO) 09/2019 - 10/2021
Mitsubishi L200 (KAOT) 04/2006 - 02/2010
Mitsubishi L200 (KAOT) 02/2010 - 10/2015
Mitsubishi Lancer (CYO) 11/2007 - 03/2016
Mitsubishi Lancer (CYO) 04/2015 - 08/2017
Mitsubishi Outlander (CWB) 07/2007 - 02/2010
Mitsubishi Outlander (CWB) 02/2010 - 10/2012
Nitsubischi Triton (L200) 2006 - 2015

Peugeot
Peugeot 4007 (V) 01/2008 - 10/2012

The following signals are provided:

Park brake
Reverse
Ignition
Illumination
Speed pulse

SWC

Rockford Fosgate OEM amplified system setting
