RATBETJENINGS INTERFACE BMW/MINI MED 17 RUNDPIN (ALL INCL)

Note:

I Bus

connector: 17 Pin BMW
connector: OEM SWC > 3,5mm Jack / loose wire

for unknown BMW connector variant > item: 42xbm00c with 17 Pin and 40 Pin Quadlock wiring harness

vehicles with Business OEM HU

vehicles without Professional OEM Sat Nav*
vehicles without OEM amplified system**

OEM devices must be disconnected:
CD-Changer / TV-Tuner / Phone module

dip switch settings for the retrofit device manufacturer (look into the manual)

Vehicle application:

BMW 3er (E46) 07/1998 - 02/2007
BMW 5er (E39) 01/1996 - 05/2004
BMW 7er (E38) 09/1994 - 09/2001
BMW X5 (E53) 03/2000 - 10/2003

BMW Mini (R50/R53) 06/2001 - 11/2006
BMW Mini (R52) 07/2004 - 08/2008

Following signals are provided:

Reimported vehicles or vehicles with different software may be incompatible in functions.

SWC

*vehicles with Professional OEM Sat Nav BMW extension 17 Pin(f) > 17 Pin(m)/antenna 6.5m bulk > item: 1020-21-6500-0
**vehicles with OEM amplified system (no DSP/Harman Kardon) Active system adapter BMW/Land Rover/Rover 17 Pin > item:13-1020-50
