Varenr.: 42xki014
På lager hos vores leverandør
Download manual
Note:
analog SWC
CAN Bus OEM amplified system
connector: 24 Pin / 18 Pin Hyundai
connector: OEM SWC > 3,5mm Jack / loose wire
vehicles with OEM amplified system
vehicles with OEM Sat Nav
check the pin assignment by measuring with the OEM HU before connecting to avoid faults or defects on the vehicle or the retrofit device
blue/white: +12V amp remote switched load stable
dip switch settings for the retrofit device manufacturer (look into the manual)
Vehicle application:
Hyundai
Hyundai ix35 (EL) 03/2010 - 09/2013
Hyundai ix35 (EL) 09/2013 - 07/2015
Hyundai i40 (VF) 09/2011 - 05/2015
Hyundai i40 (VF) 05/2015 - 08/2018
Hyundai i40 (VF) 10/2018 - 07/2019
Hyundai Sonata (YF) 2009 - 2014
Hyundai Tucson (TL) 04/2010 - 06/2015
Hyunday Veloster 2017 - 2021*
Kia
Kia Sportage (SL) 08/2010 - 03/2014
Kia Sportage (SL) 03/2014 - 01/2016
Following signals are provided:
reimported vehicles or vehicles with different software may be incompatible in functions.
SWC
OEM amplified system fader not supported
*aircondition status not longer visible
