RAT INTERFACE DUCATO PLATFORM 2021> MODELLER MED TRÅDLØS OPLADNING OG TLF SUPPORT (ALL INCL)

Note:

analog SWC
LIN Bus telefon function

connector: ISO / Mini ISO
connector: OEM SWC > 3,5mm Jack / loose wire
connector: 6 Pin Fiat T-Harness > telephone
connector: 6 Pin Fiat > loose cable T-connector LIN Bus body control unit fuse box (look into the manual)
connector: Harness body control unit fuse box > speedpuls / reverse gear signal (look into the manual)

vehicles with open dash
vehicles with inductive charging device > telephone function supported

vehicles built after 2025 6 Pin Fiat connector grey no longer available:

connection 6 Pin plug loose cable with T-connector to LIN Bus behind body control unit fuse box driver's side cockpit:
orange/purple: LIN Bus brown connector second row 9a

connection harness body control unit fuse box:
green: speed pulse signal black 60 Pin connector > Pin 22
orange: reverse gear signal +12V green 60 Pin connector > Pin 17

SWC buttons > backside steering wheel (look into the manual)
dip switch settings for the retrofit device manufacturer (look into the manual)

Vehicle application:

Citroen
Citroen Jumper (250) 07/2024 -2026
Citroen e-Jumper (259 07/2024 -2026
Citroen Relay (250) 2024 - 2026

Fiat
Fiat Ducato (ZAF 250) 11/2021 - 11/2023
Fiat Ducato (ZAF 250) 11/2023 - 2026
Fiat e-Ducato (ZAF 250) 04/2021 - 03/2024
Fiat e-Ducato (ZAF 250) 03/2024 -2026

Opel
Opel Movano Cargo C (Y) 01/2024 - 2026
Opel Movano Electrik Cargo C (Y) 01/2024 - 2026

Peugeot
Peugeot Boxer (Y) 07/2024 - 2026
Peugeot e-Boxer (Y) 07/2024 - 2026

Toyota
Toyota Proace Max (T) 08/2024 - 2026
Toyota Proace Max Electric (T) 01/2025 - 2026

The following signals are provided:

Reimported vehicles or vehicles with different software may be incompatible in functions.

SWC
