RAT INTERFACE TIL IVECO DAILY 2019>

Ratbetjeningsinterface til diverse IVECO

Note:

CAN Bus

connector: 52 Pin Fiat
connector: OEM camera > RCA(m) yellow

vehicles with Hi-Connect OEM touchscreen HU

Vehicle application:

Iveco Daily 2019 - 2023

Following signals are provided:

Reimported vehicles or vehicles with different software may be incompatible in functions.

red: +12V ignition clamp 15
orange: +12V illumination clamp 58
purple/white: +12V reverse signal
pink: speed pulse signal
green: GND park brake signal
Der skal bruges en af nedenstående kabler.
