Varenr.: 347237-1-50-p
På lager hos vores leverandør
cable diameter: 0,5 mm² - 1,5 mm²
cable diameter: 22 - 16 AWG
Technical data:
length: 31,5 mm
diameter cable entry: 4,8 mm² max.
drop length: 7,5 mm to centre stop
material: copper tin plated
insulation: Nylon (PA 66) heat shrinking with internal adhesive
shrink ratio: 3 : 1
shrink temperature: 180° min.
operating temperature: -55°C - 125°C max.
electrical current: 600V max.
Solvent resistance:
isopropyl alcohol
trichloroethylene
gasoline
battery acid
diesel fuel
motor oil
antifreeze
brake fluid
5% salt water
REACH and RoHS compliant
UL and CUL listed 91J4
Lloyds listed 65 247 HH 02-93
Waterproof
Not flame retardant
Content:
50 pieces
