Varenr.: 2 001 023 000 000
På lager hos os
Specifications
RADIO
High-End CODEM IV World-tuner,
FM, AM, DAB, DAB+ Tuner with radiotext/ DLS,
Traffic function,
alphabetical DAB+ List,
Travelstore,
Service following,
Band Introscan
MEDIAPLAYER
USB (2x),
MP2, MP3, WMA, FLAC, M4A (AAC), APE, WAV support,
Introscan,
Repeatfunction,
Mixfunction,
Apple iPod Support
BLUETOOTH
Internal and external Microfon,
Audiostreaming with trackinfo,
Voice assistant support (e.g. Siri, Google, Alexa),
Wake-up on call,
Phonebook access
SOUND
Sound presets,
Loudness,
4-channel pre-amp out+ Sub-out,
4x 50 Watt
GENERAL
Variocolour LCD (4,096 colors),
DIM- function,
Night design if switched off (Buttons),
Favoritebutton for one source,
Permanent memory,
Short body (low installation depth) ,
IR-remote option (compatible to old RC-10 remote control),
SWC option (Steering Wheel Control)
RADIO ANALOG / DIGITAL
Tuner Type: High-End Automotive Tuner Blaupunkt CODEM IV
World Tuner (switchable): EU, USA, South America, Thailand
Frequency bands: FM, AM, DAB, DAB+
Frequency band FM: 87.5 – 108 MHz
Frequency band MW: 531- 1602/ 530- 1710 kHz
Channels (frequency band) DAB/ DAB+: 5A- 13F (174,928- 239,200 MHz)
Station memory: 15x FM, 10x AM, 15x DAB
Station memory banks: FM1, FM2, FMT, AM, AMT, DAB1, DAB2, DAB3
Station memory levels deactivatable: FM2, FMT, AM, AMT, DAB2, DAB3
Station display (PS): Yes
Radiotext/ Radiotext Plus (RT/ RT+): Yes/ No
Display DLS/ ENSEMBLE/ SERVICE: Yes/ Yes/ Yes
Alternate frequency function (AF): Yes
Traffic Radio (TA) FM/ DAB: Yes/ Yes
Automatic time adjustment: Yes
Enhanced Other Networks (EON): Yes
Regional function (REG): Yes
Program type identifier (PTY)/ PTY Seek: Yes/No
Travelstore/ Number of Presets for Travelstore: Yes/ 5x FMT, 5x AMT
Band Scan/ Preset Scan: Yes/ No
Sensitivity (FM): Two levels (lo / dx)
Noise suppression (FM): Yes
Hi-Cut (FM): Yes (multi-level switchable)
DAB-DAB Service following: Yes
DAB-FM Service following: Yes
Service search: Yes
Ensemble/ Service selection: Yes/ Yes
Ensemble/ Service browsing: No/ Yes
Alphabetical Service list DAB: Yes
Frequency response FM (Hz) – 3 dB: 30 – 15.000
Frequency response DAB (Hz) +/- 3 dB: 20 – 20.000
MEDIAPLAYER
AUX-IN/ automatic detection/ activation: No
USB front: yes (type A, recessed jack)
USB rear: yes (type A, cable)
Memory card reader: No
Concealed front inputs: Yes (USB usable with flap closed)
Compatible file system of external storage devices: FAT16, FAT32, exFAT
Maximum storage size of external storage devices: > 128 GB
Maximum file/folder count of external storage devices: > 30.000
CD-/DVD-loader: No
Playback formats: MP2, MP3, WMA, APE, FLAC, AAC, MP4, WAV
Hi-Res Audio playback: No
Display options: ID3V2 (title, artist, album), folder, file, playtime
Folder & file browsing: Yes
iPod, iPhone control (iAP2, Lightning/ USB-C) Yes (USB front and rear)
Shuffle playback folder/ media: Yes/ Yes
Repeat Title/ Folder/ All: Yes/ Yes/ Yes
Introscan: Yes (4- 60 seconds adjustable)
BLUETOOTH®*
Phone call: Yes
Internal microphone: Yes
Connectivity ext. microphone: Yes
Answer/ reject call: Yes/ Yes
Access phonebook: Yes (max. 1000 numbers)
Audio streaming: Yes
Audio streaming ID3 track display: Yes (Title, Artist, Album, Playtime)
Voice assistant access (e.g. Siri, Google, Alexa): Yes
Cell phone navigation audio mix: No
Auto wake-up on call: Yes (when radio off + ignition on), deactivatable
Fast pairing without PIN: Yes
Automatic reconnection: Yes, last 5 devices
Bluetooth version: 5.0, compatible with V4.2 and V2.1 +EDR
Number of paired devices: last 5
No. of devices connected at the same time: 1
Supported profiles: A2DP, AVRCP, HFP, SPP
Audio Codecs: AAC, SBC
*Availability/ support of functions depend on the phone/ app used!
SOUND
Equalizer Number of bands/ design/ Q-filter: No
Bass/ treble adjustment: Yes / yes (+/- 7 steps)
Source specific bass/ treble adjustment: Yes
Balance/ fader: Yes / yes (+/- 7 steps)
HPF/ LPF: No
Loudness: Yes
Sound Presets: Yes (Rock, Pop, Classic)
Speaker Outputs (Channels): 4
Preamp Outputs (Channels, Voltage): 4 (RCA, < 2V)
Sub-Out: 2 (RCA, gain/ frequency variable)
Max. Power: 4 x 50 watts
Sine power at 14.4 V: 4 x 24 watts (according to DIN 45324)
