AUDIOCONTROL LC-4.800 4 KANAL FORSTÆRKER MED ACCUBASS

lc-4.800
high-power 4-channel amplifier with accubass
“Making Good Sound Great” is our passion at AudioControl and that legacy continues with the LC-4.800 multi-channel amplifier.

This unique high power design features six active speaker level inputs with summing allowing you to interface and integrate with most factory installed source units. The patent pending AccuBASS® circuit compensates for factory bass roll-off and provides maximum bass performance.

More control and features include our GTO signal Sense, Configurable Crossovers and assignable remote level control. We have incorporated years of technology into the LC-4.800 making this a perfect solution based amplifier.
features
Configurable as 4/3/2 channel amplifier
4 x 200 watts @ 2 ohms
4 x 125 watts @ 4 ohms
400 watts @ 4 ohms bridged
AccuBASS® Processing
MILC™ Maximum Input Level Control (Patent Pending)
GTO™ Signal Sense
Independent Linkwitz-Riley Alignment crossovers
Summable active speaker-level inputs (6 channels) for OEM integration
4 preamp inputs
2 assignable preamp outputs
PFM Subsonic Filter
Optional ACR-1 assignable remote control
Solid One-Piece Aluminum Chassis
specifications
inputs
Preamp Inputs: 4 balanced
Input Voltage Range: 250 mV – 8 V RMS
outputs
Rated Continuous (RMS) Power at 14.4V:
4 Ω – 125 W x 4 RMS
2 Ω – 200 W x 4 RMS
Bridged 4 Ω – 400 W RMS
Preamp Outputs: 2
Maximum Preamp Output: 8.5 V RMS
performance
Frequency Response: 10 Hz – 30 kHz
Signal to Noise: 102 dBa, Ref 200 W @ 2 Ohm
THD+N: < 0.1%
Minimum Power / Ground Wire Gauge: 3 AWG wire
Fuse Rating: 2 x 40 A
Crossover: Linkwitz-Riley, Adjustable From 30 Hz – 300 Hz
weights & dimensions
Dimensions: 9″W x 7.95″D x 2.1″H
Weight: 5.0lbs (2.0kg)
in the box: LC-4.800, Speaker connectors, Fuses, Manual, Warranty
