AUDIOCONTROL D-6.1200 6 KANAL DSP MATRIX FORSTÆRKER

Varenr.: d-6.1200
  • PRIS ER PR. Stk
    Pris ved køb af 1 Stk,7.868,00  DKK
På lager hos vores leverandør

Download manual
d-6.1200
high-power 6 channel dsp matrix amplifier with accubass
AudioControl has paired our award winning amplifier technology with our powerful Matrix DSP into the D-6.1200. This single-unit solution provides unprecedented power and tuning flexibility when you require audio perfection from your factory or aftermarket sound system.

The D-6.1200 features active speaker level inputs, line-level inputs and outputs plus, using AudioControl’s DM Smart DSP app gives you complete control over all features including 30 bands of equalization, signal delay, input delay, polarity and AudioControl proprietary features like AccuBASS®, GTOTM Signal Sense, and MILCTM plus integrated input and output RTA’s.

The built in Option Port on the D-6.1200 is the future of car audio and will allow hi-res streaming directly into the DSP. It also opens up future proprietary connections for additional inputs, controllers and interface solutions.

Perfect for OEM integration and aftermarket builds, the D-6.1200 packs power and intelligent flexibility into one beautiful cast aluminum chassis.
features
Built-in DSP
Configurable as 6/5/4/3 channel amplifier
6 x 200 watts @ 2 ohms
6 x 125 watts @ 4 ohms
400 watts @ 4 ohms bridged
AccuBASS® Processing
MILCTM Maximum Input Level Control (Patent Pending)
GTOTM Signal Sense
Active speaker-level inputs (8 channels) for OEM integration
6 preamp inputs
2 assignable preamp outputs
Solid One-Piece Aluminum Chassis
Input and Output RTA for precise and informed tuning
Input and Output Delay
12 and 24 dB/octave Linkwitz-Riley crossovers
30 band equalizer
Optional ACR-3 remote for preset recall and level control
Optional AC-BT24 Bluetooth Streamer/Programmer
Connect your laptop to the D-6.1200 using AudioControl’s DM Smart DSP app, a fully featured Matrix DSP Interface designed to give you instant and clear control over every aspect of your processor.

Route any input to any output, adjust gain, delay and polarity then precisely tune the D-6.1200 using a 30 band EQ. High-pass, low-pass and band-pass can be set up for any output using 12 or 24 dB/octave Linkwitz-Riley crossovers.

For OEM integration, take advantage of the input and output RTAs, available for every input and output, to easily identify and sum factory speaker signals.

With a clear GUI and intuitive workflow, AudioControl’s DM Smart DSP app will take the guesswork out of tuning your system to your exact specifications.

specifications
inputs
Preamp Inputs: 6 balanced
Preamp Input Voltage Range: 250 mV – 8 V RMS
Speaker Level Inputs: 8
outputs
Rated Continuous (RMS) Power at 14.4V:
4 Ω – 125 W x 6 RMS
2 Ω – 200 W x 6 RMS
Bridged 4 Ω – 400 W RMS
Preamp Outputs: 2
Maximum Preamp Output: 8.5 V RMS
performance
Frequency Response: 20 Hz – 24 kHz
Signal to Noise: 102 dBA, Ref 200 W @ 2 Ohm
THD+N: < 0.1%
Power / Ground Wire Gauge: 8 to 3 AWG wire
Fuse Rating: 3 x 40 A
weights & dimensions
Dimensions: 12.0″W x 8.0″D x 2.1″H
Weight: 7.1 lbs. (3.2 kg)
in the box: D-6.1200, Speaker Connectors, Fuses, Manual, Warranty
