Complete control and detail! The PSC is not just another DSP volume control that gives you presets and volume control. The PSC gives PS8 users the ultimate in on-the-fly tuning power and much more right at their fingertips.
The PSC is basically a small computer with its own operating system that gives users a wide range of features and options and while small and compact the PSC allows users (after their initial setup) to have near complete control of their system.
User Tuning & Control Features Include
◾Volume control
◾System Muting / unmuting (All Channels on/off)
◾Fader Control: YES – As defined by user channel assignments Via the PS8 GUI
◾System Balance Control: YES – As defined by user channel assignments Via the PS8 GUI
◾Sub Level Control - YES – As defined by user channel assignments Via the PS8 GUI
◾User Defined Center/Aux Channel Control: YES – As defined by user channel assignments Via the PS8 GUI
◾Crossover Controls: YES – Complete full crossover control for Butterworth and Linkwitz-Riley Crossovers (Slope, Dampening, Frequency)
◾Third Octave EQ: YES – Complete EQ control on all channels (Gain per band per channel, channel linking/unlinking, signal channel and/or global capabilities)
◾Signal Delay: YES- Full signal delay operation of all channels in .01ms increments
(updated to comply with the new increments of adjustment on the soon to be released PS8 GUI.)
◾Channel Phase: YES – 0 / 180 degree selectable phase on all channels via the PSC
Hardware and Display adjustable features
◾Full color OLED RGB Screen
◾All graphic colors user definable thru controller interface (Text, Background, Highlights, Images, button lighting etc) with over 256 colors to choose from allowing for complete OEM integration matching factory illumination
◾User tac switch lighting via user defined RGB lighting
◾Illumination and dimming programmable by the PSC user interface. This allows you to hook the PS8 up to your vehicles illumination circuit and define how bright you want the display and illumination on the PSC in the various states (vehicle nighttime illumination on and off)
◾Hardware user controls include a single digital rotary encoder/Tac switch and dual secondary Tac switches.
◾PSC can be rotated 180 degrees allowing the installer to mount with the encoder/controller knob to be mounted on left or right sides of the screen with switch functions changing orientation so function remains identical regardless of orientation.
◾Includes 20’ 8-pin pre-terminated cable for connection to the PS8
◾Includes mounting cradle for easy flush mounted installation.
◾Includes spring steel mounting clamp and screws for cradle mount installation
◾Case design allows or side or back cable connection to the PS8
◾PSC updates to firmware stored on PS8. Allows PSC to be transferred from PS8 to PS8 without worry of settings loss or compatibility issues
◾PSC firmware updates completed via improved interface on the PS8 GUI.
◾Digital serial number encrypted (same as PS8) for easy tracking of production units.
◾ARC Logo on home screen only
◾Live system mute form any function screen on the PSC
◾Full system on/off without the need of a remote turn on lead or signal from the PS8 allows the PSC to function (along with someth8ing like a Bluetooth transmitting device) to act as a source unit with system power control like most aftermarket and/or stock head units.
Mounting Cradle and Hardware Yes (Included)
Connection Cable to PS8 Yes - 20ft proprietary cable included)
Firmware Updates Yes - Done thru the PS8 Software Utility
Digital Encrypted Serial number Yes - Internal for product tracking purposes
Dimensions - Cradle mounting(Cutout) 1.873"(H) x 3.46" (W) x .8"(D)
Dimensions - Maximum Outer Dimensions 3.841" (L) x 2.15" (W) x 1.38" (H, Control Knob Included)
Other Products required for operation Yes - PS8
