MOREL ELATE CARBON MM3 MELLEMTONER

The Elate Carbon MM3 is a true masterpiece. The dedicated 3.5” midrange combines a large 2.1-inch voice coil and Morel’s EVC motor design which encapsulates a highly efficient neodymium magnet system, and the newly developed triple layer carbon fiber/Rohacell cone. With exceptional power handling and low fs, the MM3 is capable of playing lower in frequency than other midrange of its size, while striking the right balance of acoustic and mechanical attributes to offer a very flat frequency response, beautifully smooth midrange and tonal balance.

MM3
Nominal Impendance (ohm) 4
Power Handling Wrms 120
Max. Trans. Pwr Handling Wrms (10ms) 400
Sensitivity (2.83 V/1M) dB 87
Frequency Response Hz 90 - 6000
FS Hz 88
Voice Coil Diameter mm (inch) 54 (2.125)
Voice Coil Former Aluminium
Voice Coil Wire HexatechTM aluminium
DC Resistance ohm 3
Magnet System Neodymium Rear Vented
ConeType One-piece formed
Cone Material DPC
Unit Diameter mm (inch) 100.00 (3.9)
Mounting Dept mm (inch) 38.00 (1.5)
Mounting Cutout mm (inch) 83 (3.3)
Net Weight Kg (lb) 0.38 (0.83)
