MASSIVE AUDIO VOLT 12" 2x2ohm svingspole

The New Massive Audio VOLT Series subwoofer uses a custom designed stamp steel basket with a heavy powder coat finish that surrounds a custom tooled poly mica cone and a Massive logo embossed in an ultra-low mass woven glass fiber dust cap. In the center of the cone is the 1.5" Dual 2 Ohm voice coil with aluminum former and reinforced neck joint. It is attached to the steel frame with a pro audio 1" N-Roll polyester foam surround. The Poly-Cotton spider with woven round tinsel lead wire holds the V.C. in place and helps deliver the CEA 2031 rated 600 Max Watts/300 Watts RMS power. All this helps the 4 layer V.C. pound its way thought a single 50oz high intensity grade ferrite ring with a FEMM linear flux saturated motor design which helps control motion and reduces distortion. This combination and black E-coated magnetic plates help draw heat away from V.C. and produces volumes of kick ass bass!
•10mm Top Plate For Additional Motor Force
•Custom Designed Stamped Steel Basket w/ Heavy Powder Coat Finish
•Single 50oz High Intensity Grade Ferrite Ring Magnet
•FEMM Linear Flux Saturated Motor Design to Reduce Distortion
•Black E-Coated Magnetic Plates Draws Heat Away from Voice Coil for Cooling
•Custom Tooled Poly Mica Cone w/ Massive Logo Embossed
•1" N-Roll Polyester Foam Surround For Better Suspension
•1.5" Dual 2 ohm Voice Coils on Aluminum Former w/ Reinforced Neck Joint
•V-Shape Woven Glass Fiber Dust Cap for Profile Reinforcement



Weight

11 Pounds



Size

12"



Watts

600



RMS

300



Cone

Poly Mica



Voice Coil

1.5" Dual 2 Ohm



Surround

Dual Layer 1" Tall



Magnet

50oz High Flux Ferrite



Terminals

Spade



Basket

Stamped Steel



Tinsel Leads

Cone Woven



X-Max

24mm peak to peak



SPL

89dB



Fs

32Hz



Ported Box

14H x 16W x 17.5D (Round Port 4" x 8")



Sealed Box

14H x 14W x 14D
