Varenr.: 346301-3-5-p
På lager hos vores leverandør
cable diameter: 4,0 mm² - 6,0 mm²
cable diameter: 12 - 10 AWG
Technical data:
contact: 6,3 mm x 0,8 mm
length: 20,8 mm
contact opening: 6,6 mm x 0,7 mm
diameter cable entry: 6,3 mm² max.
diameter strand: 3,4 mm² max.
sleeve length: 13,9 mm
plug length: 7,2 mm
material: brass tin plated
insulation: vinyl PVC
operating temperature: -10 °C - 75 °C
electrical current: 300V max.
electrical rating: 24A max.
REACH and RoHS compliant
Content:
5 pieces
