Varenr.: 342801-1-0-p
På lager hos vores leverandør
cable diameter: 0,5 mm² - 1,5 mm²
cable diameter: 22 - 16 AWG
Technical data:
contact: 2,8 mm x 0,5 mm
length: 18,8 mm
contact opening: 3,1 mm x 0,7 mm
diameter cable entry: 3,9 mm² max.
diameter strand: 1,7 max.
sleeve length: 10,0 mm
plug length: 6,5 mm
material: brass tin plated
insulation: vinyl PVC
operating temperature: -10 °C - 75 °C
electrical current: 300V max.
electrical rating: 10A max.
REACH and RoHS compliant
UL-listed
Content:
100 pieces
