CARPOWER SP-167C (6,5")

Perfect Car Hi-fi Subwoofers for Free Air Applications

Coated paper cone with reinforced rings and long excursion surround of special design. The magnetic systems were improved yet again and now provide an even higher drive power, the approved far protruding lower pole plate ensures an exceptionally high excursion accordingly.

Car hi-fi bass-midrange speaker, 150WMAX, 4ohm

16cm (6¨) bass-midrange speaker with coated cone. Also suitable for replacing kick bass speakers of free air applications in compact vehicles. New improved design with protruding lower pole plate for an even longer excursion.

With the new drive parameters which show a clearly improved Q factor (Qts), these speakers can now be recommended for closed cabinets and even bass-reflex cabinets with large dimensions, too
TEKNISKE DATA:
Impedance (Z) 4ohm
Frequency range 58-5,500Hz
Resonant frequency (fs) 49Hz
Crossover frequency (12dB/oct.) (fmax) 3,000Hz
Peak rating 150W
Power rating 50WRMS
SPL (1W/1m) 91dB
Cms suspension compliance 0.84mm/N
Mms moving mass 12g
Qms mech. Q factor 2.89
Qes electrical Q factor 0.45
Qts total Q factor 0.39
Compl. equiv. vol. (Vas) 22 l
DC resistance (Re) 3.7¥Ø
Voice coil ind. (1kHz) (Le) 0.2mH
Voice coil diameter 25mm
Voice coil former aluminium
Air gap height 4mm
Force factor WxL 5.6Tm
Eff. cone area (Sd) 137cm2
Magnet diameter 100mm
Magnet weight 570g
Mounting cutout ¨ª 148mm
Mounting depth 80mm
Dimensions ¨ª 170mm
Weight 1.15kg
