ARC AUDIO Black 6.2

•Designed and engineered in Denmark by leading audiophile speaker design engineers
•Audiophile design specifically for the car audio environment
•Precision machined glass fiber voice coil formers for ultra low mechanical loss and extraordinary dampening control
•Low Shore TLS injected rubber composite surround
•Symmetrical compliance custom progressive woven Nomex spider
•Open vented rear spider and voice coil assembly eliminates back wave compression increasing the speakers linearity and stability at a wider frequency bandwidth
•CNC precision cut extended copper capped pole piece assembly minimizes modulation distortion and varying voice coil induction significantly increasing bandwidth, speaker transparency and transient response
•Laminated Pulp/Bamboo fiber reinforced cone gives the Black series an ultra low moving mass greatly improving the speakers sound quality and the ability to react efficiently to dynamic music passages without cone break up or distortion at high volume
•Precision would voice coils and a multi stage adhesive tempering process allows for improved power handling even over ultra high demand periods
•Black series voice coils undergo a 4 stage progressive temperature tempering process increasing the coils thermal rating to an industry leading 260 degree Celsius
•All black series speakers undergo an extensive 5 stage testing protocol allowing every driver to be verified to meet or exceed ARC Audio technical specifications across the entire published bandwidth of the speaker
•Black series speakers are sold in Matched pairs or in full component systems composite silk fiber dome tweeter
•Simple cosmetic design for easier vehicle integration Includes HPX (High Pass) and LPX (Low Pass) audiophile user defined crossover networks
•User defined options on passive networks include Slope, Attenuation and Frequency selection
•Crossovers use primarily all hand picked air core inductors and metalized poly propylene components for maximum clarity and transparency
•Black series speakers include CNC cut MDF speaker rings for custom installations or even just as spacers for door installations

Midwoofer Diameter 6.5"
MW Power Handling (Peak) 200 Watts
MW Power Handling (RMS) 85 Watts
MW Frequency Response 45Hz - 3.5kHz
MW Sensitivity 92dB
MW Impedance 4 ohms
MW Basket Material Hi Pressure Cast Aluminum
MW Cone Material Pulp/Bamboo Fiber
MW Surround material Low Shore TLS Rubber Composite
MW Spider Material Sym Progressive Nomex
MW Motor Structure Multi Step CNC Precision cut
MW Copper Shorting Plug Yes
MW Voice Coil Machined Glass Fiber/Copper
Tweeter Diameter 29mm
TW Power Handling (Peak) 120 Watts
TW Power Handling (RMS) 60 Watts
TW Sensitivity 92dB
TW Frequency Response 800Hz - 22kHz
TW Impedance 4 ohms
