ARC AUDIO Black 10V2 D4

The true balance of dynamic grace and pure chaos the Black Series subwoofer line is ARC Audio's answer to any level of car audio enthusiast or audiophile.

Designed and engineered by one of the worlds leading pro audio speaker design engineers in conjunction with ARC Audio in house speaker design and development team the Black Series subwoofer line uses only the latest high performance materials and composites with an uncompromised approach to sonic perfection.

Just like the Black Series Speaker line, Black Series Subwoofers are engineered and designed with focus placed on transparency, performance and the natural reproduction of music the way it was intended to be heard but with the reinforced ability to provide users with heart stopping dynamic bass and emotion.

With over 27 years of audiophile speaker engineering design behind this line the Black Series offers only the purest, smoothest and most dynamic un-timbered sound available in the car audio industry.

ARC Audio Black Series Subwoofers are available in dual 2 and 4 ohm configurations and are available only thru authorized ARC Audio brick and mortar store front retailers and at www.arcaudio.com.

◾ Advanced Hi Fi Subwoofer Design
◾ Hi pressure cast CNC cut aluminum basket
◾ Precision wound 3" hi temp voice coil
◾ 4 stage hi temperature voice coil tempering process
◾ Non-Conductive machined fiberglass composite voice coil former
◾ Hi capacity heavy duty spring loaded speaker terminals
◾ Low shore progressive SLA rubber surround
◾ Progressive rate Nomex PTE woven spider
◾ Linear Audiophile SQ/SPL design specifically for the car audio environment
◾ 12 Stage testing and QC protocol on every Black Series subwoofer to ensure all drivers meet or exceed ARC Audio specifications for the demanding car audio environment
◾ Mounting Depth 5 11/16"
◾ Cutout Diameter 9 3/16"
◾ Minimum sealed enclosure - .65 cuft.
◾ Optimum sealed enclosure - .85 cuft.
◾ SPL sealed enclosure - 1.1 cuft.

Power Handling (Peak) 800 Watts
Power Handling (RMS) 400 Watts
Xmax 16mm
Ohms Dual 4 ohm
Minimum Sealed Enclosure .65 Cuft
Optimum Sealed Enclosure .85 cuft
Maximum Sealed Enclosure 1.1 cuft
Cutout Diameter 9 3/16"
Mounting Depth 6 3/8"
