Fusion Power Plant AM8004

1 tilbage

85 Watts RMS x 4 @ 4 Ohms and 1% THD+N
110 Watts RMS x 4 @ 2 Ohms and 1% THD+N
225 Watts RMS brokoblet @ 4 Ohms and 1% THD+N

Max Power Rating: 800 Watts
Max Current: 60A
Full Rated Power Distortion (Max) 1kHz: 0.04%
THD @ Rated Power 1kHz/100Hz: 0.1%
Channel Separation:[b/] 50
Frequency Response Hz (-3dB): 10Hz - 40kHz
Signal to Noise: >90
Variable High Pass Filter: 12 dB/Octave
Variable Low Pass Filter: 12 dB/Octave
Bass Boost @ 45Hz: 12dB
Input Sensitivity: 0.2 - 8V
Input Impedance: 47K
Fuse Rating: 25A x 3
