Varenr.: EM-MBR2
På lager hos vores leverandør
Download manual
EM-MBR2
Upgrade Coaxial Speaker for Mercedes-Benz
4″ / 10 cm
Plug & Play connection terminals
Strong neodymium magnet
Aluminum cone, rubber surround
16 mm tweeter with a fabric dome
Crossover with 6 dB highpass filter @ 150 Hz and 12 dB / 6 dB filter @ 4300 Hz
Power handling 25 W RMS
With this new speaker series EMPHASER creates an outstanding sound experience for Mercedes vehicles. The carefully selected components allow an extraordinary richness of detail and an immense depth - with high-quality crossovers perfectly matched for a harmonious music enjoyment.
The aluminum cone of the midrange is responsible for the true and detailed sound. The sound conductivity and rigidity of this material ensure a high neutrality and linearity in music reproduction.
The crystal-clear tweeter with 16 fabric dome starts at 4'300 Hz. Instruments and voices are perceived at the level of the windshield, making listening to your favorite music even more enjoyable.
The EM-MBR2 is delivered with a comprehensive but compact crossover - for a perfect result in the vehicle. The tweeter and midrange are playing alike out of one piece, so that the music and voices seem to float in the room, vivid and authentic.
The crossover provides a 12dB / 6dB filtering with high quality components for mid and high, including tweeter level adjustment 0 / + 3dB. The also integrated high-pass filter for the midrange cuts off very low frequencies from the signal. All connections of the speakers and crossovers fit perfectly to the plugs of the vehicle. The installation is therefore unequivocal and is accomplished in about half an hour.
2-way 4" coaxial speaker
Frequency response: 150 Hz – 20 kHz
Nominal impedance: 4 ohms
Sensitivity 1W/1m: 87 dB
Continuous power handling: 30 Wrms
